DMC8032R
DISC MOWER CONDITIONERS
Call for Pricing
From the 3 bladed disc and fully welded cutterbar to the Chevron roller with protective, spring tensioning system, the Kubota DMC8032R is designed to give your crops effective and gentle handling. The working width of the disc mower conditioner comes in at 10’ 6”, but with the transportation kit, you’ll narrow down that number to 9’ 1”.Several kits can be added on to make your life that much easier when changing knives or increasing the working width.
Specifications
Alternative Cond. Speed Kit
Cond. Rotor Speed
Conditioner
Cutterbar Operating Angle
Cutting Height In.
Drawbar
High Skids In.
Hitch
Hitch ( C A T)
Lighting Kit
Minimum P T O Horsepower Required H P/ K W
Number Of Disc And Knives
P T O R P M
Remotes
Stubble Height In. (mm)
Throwing Wings For Diff. Crops
Tires
Transport Width Ft. (m)
Weight Lbs. (kg)
Wide Spreading Kit
Working Width Ft. (m)
Alternative Cond. Speed Kit
1200
Cond. Rotor Speed
900
Conditioner
Chevron Roller
Cutterbar Operating Angle
±15
Cutting Height In.
1.25-3.25
Drawbar
Left hand
High Skids In.
Optional/Optional/Optional
Hitch
Drawbar, Swivel, Gearbox
Hitch ( C A T)
Cat II
Lighting Kit
Standard
Minimum P T O Horsepower Required H P/ K W
60/80
Number Of Disc And Knives
8
P T O R P M
540 standard / 1000 optional
Remotes
2
Stubble Height In. (mm)
1.18"-1.57"
Throwing Wings For Diff. Crops
Standard
Tires
380/55-17
Transport Width Ft. (m)
9' 8" (2.9)
Weight Lbs. (kg)
4150 (1882)
Wide Spreading Kit
Optional
Working Width Ft. (m)
10' 6" (3.2)
